Spiral Wound Exhaust Pipe Gasket
Item No.:ZD-G1202
Description:A
spiral-wound gasket includes a plurality of tightly wound metal windings
to form a core. The windings each have a Chervon cross-section, wherein
V-notched undulations of each winding registers with an adjacent winding
at said notches. The edges of the windings are welded to form a
pre-assembled integral composite that is installed into a J-shaped outer
wrap or cover. Finally, the cover is closed about the core so as to
entirely cover and encapsulate the core. In a preferred form, both the
core and outer cover are formed of stainless steel materials.Metal
Spiral Wound Exhaust Pipe Gasket For Motorcycle and Automobile Exhaust
Pipe.It is used in motorcycle and
automobile exhaust pipe system for sealing.There is "W" shape or "V"
shape workable.And it's
convenient to install or replace.
The Material:Usually,we
use SSS316 or SS304 for higher temperature and rusted exhaust pipe
system.But if there is no corrosion,the SS201,SS202 or tin-plated metal
hoop are also workable.And the filler can be graphte(marked as
FG),asbestos,non-asbestos,mica or ceramic tape.They are for different
exhaust system.
Related Talble for
Consult:
|
media material |
asbestos |
graphite |
non-asbestos |
Ceramic |
Mica |
|
Water-type media |
600℃，CL 2500 |
550℃，CL 1500 |
350℃，CL 1500 |
800℃， CL 1500 |
700℃，CL 1500 |
|
oil-type media |
500℃，CL 1500 |
550℃，CL 600 |
350℃，CL 600 |
- |
- |
|
gas-type media |
400℃，CL 600 |
550℃，CL 400 |
350℃，CL 400 |
- |
- |
The main style of spiral wound gasket：
1.Tinplate with white
asbestos/non-asbestos/graphite
2.SUS304 with asbestos/non-asbestos/graphite
3.SS201 with red
asbestos/non-asbestos/graphite
Special material can be produced as request
